储能电站锂离子电池火灾早期预警与抑制技术研究综述*

doi:10.11985/2022.04.009

摘要/Abstract

摘要：

锂离子电池的优良性能使之得到了广泛的应用，也是电化学储能电站的核心部件之一。然而储能电站的火灾、爆炸等事故，不但会给企业带来极大的经济损失，还会对整个产业的发展产生很大的影响，因此储能电站安全不容忽视。阐述了锂离子电池热失控致火灾的机理，重点归纳总结了当前国内外关于电池表面缺陷检测、电压、电流-超声波预警系统、声音预警系统和气体-声信号预警系统融合等锂离子电池热失控-火灾早期预警技术，研究了现有锂离子电池火灾灭火常用技术手段及优缺点。在此基础上，提出了适用于锂离子电池储能电站火灾的早期预警和火灾控制技术，为有效地提升储能系统安全防护水平，降低火灾发生的概率及火灾发生后的财产损失等应用提供了参考。

关键词: 锂离子电池, 储能电站, 火灾预警, 火灾抑制

Abstract:

The excellent performance of lithium-ion batteries makes them widely used, and it is also one of the core components of electrochemical energy storage power stations. However, accidents such as fires and explosions of energy storage power stations not only bring great economic losses to enterprises, but also have great impact on the development of the entire industry. Therefore, the safety of energy storage power stations cannot be ignored. The mechanism of lithium-ion battery thermal runaway and fire, and focuses on summarizing the runaway and fire early warning technology, such as current domestic and foreign research on battery surface defect detection, voltage, current-ultrasonic early warning system, sound early warning system and gas-acoustic signal early warning system fusion are expounded. The common technical means and advantages and disadvantages of existing lithium-ion battery fire extinguishing are also studied. On this basis, a fire early warning and fire control technology suitable for lithium-ion battery energy storage power stations is proposed, which can effectively improve the safety protection level of energy storage systems, reduce the probability of fire occurrence and property damage after fire occurrence.

Key words: Lithium-ion battery, energy storage power station, fire warning, fire suppression

中图分类号:

陈银, 肖如, 崔怡琳, 陈明毅. 储能电站锂离子电池火灾早期预警与抑制技术研究综述^*[J]. 电气工程学报, 2022, 17(4): 72-87.

CHEN Yin, XIAO Ru, CUI Yilin, CHEN Mingyi. Research Review on Early Warning and Suppression Technology of Lithium-ion Battery Fire in Energy Storage Power Station[J]. Journal of Electrical Engineering, 2022, 17(4): 72-87.

图/表 13

表1

图1

图2

图3

图4

图5

图6

图7

图8

图9

图10

表2

图11

参考文献 70

[1]	晏平刚, 冒兴峰, 曾惠娜, 等. 纯电动客车动力电池舱火灾多级预警系统设计[J]. 时代汽车, 2021(24):123-125.
	YAN Pinggang, MAO Xingfeng, ZENG Huina, et al. Design of multi-level fire early warning system for power battery compartement of electric bus[J]. Auto Time, 2021(24):123-125.
[2]	赵洪强. 论储能电站火灾预防措施[J]. 今日消防, 2022, 7(6):76-78.
	ZHAO Hongqiang. On fire protection of energy storage power station[J]. Fire Protection Today, 2022, 7(6):76-78.
[3]	贾超, 赵霞, 张妍. 锂电池储能电站火灾风险分析与对策探讨[J]. 电力安全技术, 2022, 24(6):23-26.
	JIA Chao, ZHAO Xia, ZHANG Yan. On the fire risk analysis and strategies for lithium battery energy storage power stations[J]. Electric Safety Technology, 2022, 24(6):23-26.
[4]	杨涛, 文贤馗, 谈竹奎, 等. 面向新型电力系统储能电站的锂电池荷电状态评估方法研究[J]. 电测与仪表:1-9[2022-07-14]. http://kns.cnki.net/kcms/detail/23.1202.th.20220714.0959.004.html.
	YANG Tao, WEN Xiankui, TAN Zhukui, et al. Research on SOC evaluation method of lithium battery for energy storage station in novel power system[J]. Electrical Measurement and Instrumentation:1-9[2022-07-14]. http://kns.cnki.net/kcms/detail/23.1202.th.20220714.0959.004.html.
[5]	周云鹏, 李莹滢. 电化学储能电站火灾特点及灭火剂选用分析[J]. 山东化工, 2022, 51(9):192-194.
	ZHOU Yunpeng, LI Yingying. Discussion on the characteristics of electrochemical energy storage station fire accident and selection of fire extinguishing agent[J]. Shandong Chemical Industry, 2022, 51(9):192-194.
[6]	杨君涛, 张永丰, 张磊. 电化学储能电站火灾风险分析与评估指南研究[J]. 现代职业安全, 2021(11):26-29.
	YANG Juntao, ZHANG Yongfeng, ZHANG Lei. Study on guidelines for fire risk analysis and assessment of electrochemical energy storage power plants[J]. Modern Occupational Safety, 2021(11):26-29.
[7]	许佳佳, 王青松. 电化学储能电站火灾的防与控[J]. 劳动保护, 2021(12):17-19.
	XU Jiajia, WANG Qingsong. Fire prevention and control of electrochemical energy storage power station[J]. Labour Protection, 2021(12):17-19.
[8]	胡振恺, 李勇琦, 彭鹏. 电池储能系统火灾预警与灭火系统设计[J]. 消防科学与技术, 2020, 39(10):1434-1438.
	HU Zhenkai, LI Yongqi, PENG Peng. Design of fire warning system and fire extinguishing system of battery energy storage system[J]. Fire Science and Technology, 2020, 39(10):1434-1438.
[9]	WANG Qingsong, PING Ping, ZHAO Xuejuan, et al. Thermal runaway caused fire and explosion of lithium-ion battery[J]. Journal of Power Sources, 2012, 208:210-224. doi: 10.1016/j.jpowsour.2012.02.038
[10]	RIBIÈRE P, GRUGEON S, MORCRETTE M, et al. Investigation on the fire-induced hazards of Li-ion battery cells by fire calorimetry[J]. Energy & Environmental Science, 2012, 5(1):5271-5280.
[11]	周洋捷, 王震坡, 洪吉超, 等. 新能源汽车动力电池“过充电-热失控”安全防控技术研究综述[J]. 机械工程学报, 2022, 58(10):112-135. doi: 10.3901/JME.2022.10.112
	ZHOU Yangjie, WANG Zhenpo, HONG Jichao, et al. Review of overcharge-to-thermal runaway and the control strategy for lithium-ion traction batteries in electric vehicles[J]. Journal of Mechanical Engineering, 2022, 58(10):112-135. doi: 10.3901/JME.2022.10.112
[12]	JINDAL P, BHATTACHARYA J. Review:Understanding the thermal runaway behavior of Li-ion batteries through experimental techniques[J]. Journal of The Electrochemical Society, 2019, 166(10):A2165-A2193.
[13]	皇甫趁心. 动力锂电池火灾热失控早期探测技术及装置开发[D]. 泉州: 华侨大学, 2018.
	HUANGFU Chenxin. The early fire detection technology and equipment development of power lithium battery thermal runaway[D]. Quanzhou: Huaqiao University, 2018.
[14]	山彤欣, 王震坡, 曲昌辉, 等. 新能源汽车动力电池“机械滥用-热失控”及其安全防控技术综述[J]. 机械工程学报, 2022, 58(14):252-275. doi: 10.3901/JME.2022.14.252
	SHAN Tongxin, WANG Zhenpo, QU Changhui, et al. Overview of “mechanical abuse-thermal runaway” of electric vehicle power battery and Its safety prevention and control technology[J]. Journal of Mechanical Engineering, 2022, 58(14):252-275. doi: 10.3901/JME.2022.14.252
[15]	WANG H, LARA-CURZIO E, RULE E T, et al. Mechanical abuse simulation and thermal runaway risks of large-format Li-ion batteries[J]. Journal of Power Sources, 2017(342):913-920.
[16]	许海彪. 基于深度学习的锂电池壳表面缺陷视觉检测研究[D]. 秦皇岛: 燕山大学, 2021.
	XU Haibiao. Research on visual inspection of surface defects of lithium battery case based on deep learning[D]. Qinhuangdao: Yanshan University, 2021.
[17]	王刚. 基于深度学习的锂电池褶皱检测系统的研究与实现[D]. 沈阳: 辽宁大学, 2019.
	WANG Gang. Research and implementation of lithium battery wrinkle detection system based on deep learning[D]. Shenyang: Liaoning University, 2019.
[18]	桂久琪, 李林升, 毛晓, 等. 基于改进YOLOv4的锂电池缺陷检测方法[J]. 电子测量技术, 2022, 45(15):144-150.
	GUI Jiuqi, LI Linsheng, MAO Xiao, et al. Lithium battery defect detection method based on improved YOLOv4[J]. Electronic Measurement Technology, 2022, 45(15):144-150.
[19]	李瑞坤. 基于多尺度特征的锂电池表面缺陷检测方法研究[D]. 哈尔滨: 哈尔滨工业大学, 2019.
	LI Ruikun. Surface defect detection for lithium battery based on multi-scale features[D]. Harbin: Harbin Institute of Technology, 2019.
[20]	封学勇. 基于深度学习的柱形锂电池钢壳表面缺陷识别与分类方法[D]. 合肥: 合肥工业大学, 2020.
	FENG Xueyong. Recognition and classification of surface defects of cylindrical lithium battery steel shell based on deep learning[D]. Hefei: Hefei University of Technology, 2020.
[21]	张志国. 基于智能学习的电池片表面缺陷视觉检测算法研究[D]. 广州: 华南理工大学, 2019.
	ZHANG Zhiguo. Research on visual detection algorithm for surface defects of cell based on intelligent learning[D]. Guangzhou: South China University of Technology, 2019.
[22]	林格. 基于AI技术的锂离子电池存储区火灾早期探测技术研究[J]. 消防科学与技术, 2022, 41(5):686-689,693.
	LIN Ge. Research on early fire detection technology of lithium-ion battery storage area based on Al technology[J]. Fire Science and Technology, 2022, 41(5):686-689,693.
[23]	BOMMIER C, CHANG W, LU Y, et al. In operando acoustic detection of lithium metal plating in commercial LiCoO₂/Graphite pouch cells[J]. Cell Reports Physical Science, 2020:100035.
[24]	HSIEH A G, BHADRA S, HERTZBERG B J, et al. Electrochemical-acoustic time of flight:In operando correlation of physical dynamics with battery charge and health[J]. Energy & Environmental Science, 2015, 8(5):1569-1577.
[25]	LUKAS G, TOBIAS B, WOLFGANG V, et al. Probing lithium-ion batteries’ state-of-charge using ultrasonic transmission:Concept and laboratory testing[J]. Journal of Power Sources, 2017, 343:536-544. doi: 10.1016/j.jpowsour.2017.01.090
[26]	胡南. 基于倾斜光纤光栅传感探针的锂电池枝晶生长原位检测研究[D]. 广州: 暨南大学, 2020.
	HU Nan. In-situ detection of dendrite growth in lithium battery using tilted fiber grating sensors[D]. Guangzhou: Jinan University, 2020.
[27]	PHAM M, DARST J J, FINEGAN D P, et al. Correlative acoustic time-of-flight spectroscopy and X-ray imaging to investigate gas-induced delamination in lithium-ion pouch cells during thermal runaway[J]. Journal of Power Sources, 2020, 470:228039. doi: 10.1016/j.jpowsour.2020.228039
[28]	SU Tonglun, LYU Nawei, ZHAO Zhixing, et al. Safety warning of lithium-ion battery energy storage station via venting acoustic signal detection for grid application[J]. Journal of Energy Storage, 2021, 38:102498. doi: 10.1016/j.est.2021.102498
[29]	HAO Wenfeng, YUAN Zengrui, LI Dandan, et al. Study on mechanical properties and failure mechanism of 18650 lithium-ion battery using digital image correlation and acoustic emission[J]. Journal of Energy Storage, 2021, 41:102894. doi: 10.1016/j.est.2021.102894
[30]	MAURA C A, JEFFREY A K, STEVEN A A, et al. Avoiding thermal runaway in lithium-ion batteries using ultrasound detection of early failure mechanisms[J]. Journal of Power Sources, 2022, 535:231423. doi: 10.1016/j.jpowsour.2022.231423
[31]	KIM J Y, WANG Z L, LEE S M, et al. Failure analysis of thermally abused lithium-ion battery cell by microscopy,electrochemical impedance spectroscopy,and acoustic emission[J]. Microelectronics Reliability, 2019,100-101:113363.
[32]	HUANG Peifeng, PING Ping, LI Ke, et al. Experimental and modeling analysis of thermal runaway propagation over the large format energy storage battery module with Li₄Ti₅O₁₂ anode[J]. Applied Energy, 2016, 183:659-673. doi: 10.1016/j.apenergy.2016.08.160
[33]	LIU Pengjie, SUN Huanli, QIAO Yantao, et al. Experimental study on the thermal runaway and fire behavior of LiNi_0.8Co_0.1Mn_0.1O₂ battery in open and confined spaces[J]. Process Safety and Environmental Protection, 2022, 158:711-726. doi: 10.1016/j.psep.2021.12.056
[34]	WANG Zhengyang, JIANG Xuepeng, KE Wei, et al. Effect of lithium-ion battery diameter on thermal runaway propagation rate under one-dimensional linear arrangement[J]. Thermal Science and Engineering Progress, 2022, 31:101301. doi: 10.1016/j.tsep.2022.101301
[35]	张绪祥. 基于SVM的锂电池仓火灾预警及灭火系统[D]. 西安: 长安大学, 2019.
	ZHANG Xuxiang. SVM-based lithium battery compartment fire warning and fire extinguishing system[D]. Xi’an: Chang’an University, 2019.
[36]	ZHANG Qingsong, LIU Tiantian, WANG Qiong. Experimental study on the influence of different heating methods on thermal runaway of lithium-ion battery[J]. Journal of Energy Storage, 2021, 42:103063. doi: 10.1016/j.est.2021.103063
[37]	YANG Yun, WANG Zhirong, GUO Pinkun, et al. Carbon oxides emissions from lithium-ion batteries under thermal runaway from measurements and predictive model[J]. Journal of Energy Storage, 2021, 33:101863. doi: 10.1016/j.est.2020.101863
[38]	施志成, 周勇, 程旭东. 锂离子电池电解液火灾的烟雾探测方法研究[J]. 火灾科学, 2021, 30(2):107-112.
	SHI Zhicheng, ZHOU Yong, CHENG Xudong. Study on smoke detection method for electrolyte fire of lithium-ion battery[J]. Fire Safety Science, 2021, 30(2):107-112.
[39]	李聪, 周勇. 锂离子电池火灾烟雾不对称比研究[J]. 中国安全科学学报, 2022, 32(4):93-98. doi: 10.16265/j.cnki.issn1003-3033.2022.04.014
	LI Cong, ZHOU Yong. Study on asymmetry ratio of Li-ion battery fire smoke[J]. China Safety Science Journal, 2022, 32(4):93-98. doi: 10.16265/j.cnki.issn1003-3033.2022.04.014
[40]	LIU Pengjie, LIU Chaoqun, YANG Kai, et al. Thermal runaway and fire behaviors of lithium iron phosphate battery induced by over heating[J]. Journal of Energy Storage, 2020, 31:101714. doi: 10.1016/j.est.2020.101714
[41]	王春力, 贡丽妙, 亢平, 等. 锂离子电池储能电站早期预警系统研究[J]. 储能科学与技术, 2018, 7(6):1152-1158.
	WANG Chunli, GONG Limiao, KANG Ping, et al. Research on early warning system of lithium-ion battery energy storage power station[J]. Energy Storage Science and Technology, 2018, 7(6):1152-1158.
[42]	LARSSON F, BERTILSSON S, FURLANI M, et al. Gas explosions and thermal runaways during external heating abuse of commercial lithium-ion graphite-LiCoO₂ cells at different levels of ageing[J]. Applied Energy, 2018, 373:220-231.
[43]	李毅, 于东兴, 张少禹, 等. 典型锂离子电池火灾灭火试验研究[J]. 安全与环境学报, 2015, 15(6):120-125.
	LI Yi, YU Dongxing, ZHANG Shaoyu, et al. On the fire extinguishing tests of typical lithium-ion battery[J]. Journal of Safety and Environment, 2015, 15(6):120-125.
[44]	ZHU Mingxing, ZHU Shunbing, GONG Junhui, et al. Experimental study on fire and explosion characteristics of power lithium batteries with surfactant water mist[J]. Procedia Engineering, 2018, 211:1083-1090. doi: 10.1016/j.proeng.2017.12.113
[45]	XU Jiajia, DUAN Qiangling, ZHANG Lin, et al. The enhanced cooling effect of water mist with additives on inhibiting lithium ion battery thermal runaway[J]. Journal of Loss Prevention in the Process Industries, 2022, 77:104784. doi: 10.1016/j.jlp.2022.104784
[46]	刘昱君, 段强领, 黎可, 等. 多种灭火剂扑救大容量锂离子电池火灾的试验研究[J]. 储能科学与技术, 2018, 7(6):1105-1112.
	LIU Yujun, DUAN Qiangling, LI Ke, et al. Experimental study on fire extinguishing of large-capacity lithium-ion batteries by various fire extinguishing agents[J]. Energy Storage Science and Technology, 2018, 7(6):1105-1112.
[47]	SI Rongjun, LIU Deqi, XUE Shaoqian. Experimental study on fire and explosion suppression of self-ignition of lithium-ion battery[J]. Procedia Engineering, 2018, 211:629-634. doi: 10.1016/j.proeng.2017.12.057
[48]	LIU Yujun, YANG Kai, ZHANG Mingjie, et al. The efficiency and toxicity of dodecafluoro-2- methylpentan-3-one in suppressing lithium-ion battery fire[J]. Journal of Energy Chemistry, 2022(2):532-540.
[49]	ZHANG Lin, LI Yongqi, DUAN Qiangling, et al. Experimental study on the synergistic effect of gas extinguishing agents and water mist on suppressing lithium-ion battery fires[J]. Journal of Energy Storage, 2020, 32:101801. doi: 10.1016/j.est.2020.101801
[50]	林震, 田浩, 周晓蓉, 等. 储能系统锂离子电池火灾抑制技术分析和研究[J]. 消防科学与技术, 2021, 40(12):1793-1796.
	LIN Zhen, TIAN Hao, ZHOU Xiaorong, et al. Analysis and research on Li-ion battery fire suppression technology for energy storage system[J]. Fire Science and Technology, 2021, 40(12):1793-1796.
[51]	王赫, 朱顺兵, 张宇航. 含添加剂细水雾抑制三元锂离子电池火灾试验研究[J]. 消防科学与技术, 2022, 41(3):319-324.
	WANG He, ZHU Shunbing, ZHANG Yuhang, et al. Experimental study on fire suppression of ternary lithium-ion battery by water mist with additive[J]. Fire Science and Technology, 2022, 41(3):319-324.
[52]	朱明星, 朱顺兵, 罗炜涛. 含表面活性剂细水雾抑制锂离子电池火灾研究[J]. 消防科学与技术, 2018, 37(6):799-803.
	ZHU Mingxing, ZHU Shunbing, LUO Weitao. Study on fire suppression of lithium batteries with surfactant water mist[J]. Fire Science and Technology, 2018, 37(6):799-803.
[53]	张博. 含添加剂细水雾对锂离子电池火灾的抑制作用研究[D]. 镇江: 江苏大学, 2021.
	ZHANG Bo. Study on fire suppression mechanism of lithium-ion batteries by water mist containing additives[D]. Zhenjiang: Jiangsu University, 2021.
[54]	WANG Wenhe, HE Sen, HE Tengfei, et al. Suppression behavior of water mist containing compound additives on lithium-ion batteries fire[J]. Process Safety and Environmental Protection, 2022, 161:476-487. doi: 10.1016/j.psep.2022.03.062
[55]	LIU Yujun, DUAN Qiangling, XU Jiajia, et al. Experimental study on a novel safety strategy of lithium-ion battery integrating fire suppression and rapid cooling[J]. Journal of Energy Storage, 2020, 28:101185. doi: 10.1016/j.est.2019.101185
[56]	张乃平, 马永飞, 杨孟霖, 等. 锂电池火灾灭火技术研究综述[J]. 中国安全生产科学技术, 2022, 18(7):47-53.
	ZHANG Naiping, MA Yongfei, YANG Menglin, et al. Review on fire extinguishing technology research of lithium battery[J]. Journal of Safety Science and Technology, 2022, 18(7):47-53.
[57]	KAZUMA K, HAJIME M, YO K, et al. Gas generation mechanism due to electrolyte decomposition in commercial lithium-ion cell[J]. Journal of Power Sources, 1999,81-82:715-719.
[58]	YU Zhe, ZHANG Jianjun, WANG Chao, et al. Flame-retardant concentrated electrolyte enabling a Li F-rich solid electrolyte interface to improve cycle performance of wide-temperature lithium-sulfur batteries[J]. Journal of Energy Chemistry, 2020, 29(12):154-160.
[59]	尹继辉. 阻燃添加剂DMMP对电解液着火燃烧特性影响试验研究[D]. 成都: 西南交通大学, 2021.
	YIN Jihui. Experimental study on the influence of flame retardant additive DMMP on ignition and combustion characteristics of electrolyte[D]. Chengdu: Southwest Jiaotong University, 2021.
[60]	MEI Jie, LIU Hong, CHEN Mingyi. Experimental study on combustion behavior of mixed carbonate solvents and separator used in lithium-ion batteries[J]. Journal of Thermal Analysis and Calorimetry, 2020, 139(2):1255-1264. doi: 10.1007/s10973-019-08502-3
[61]	WU Bingbin, FENG Pei, YUE Wu, et al. An electrochemically compatible and flame-retardant electrolyte additive for safe lithium ion batteries[J]. Journal of Power Sources, 2013, 227:106-110. doi: 10.1016/j.jpowsour.2012.11.018
[62]	DAGGER T, LUERENBAUM C, SCHAPPACHER F M, et al. Electrochemical performance evaluations and safety investigations of pentafluoro (phenoxy) cyclotriphosphazene as a flame retardant electrolyte additive for application in lithium ion battery systems using a newly designed apparatus for improved self-extinguishing time measurements[J]. Journal of Power Sources, 2017, 342:266-272. doi: 10.1016/j.jpowsour.2016.12.007
[63]	LI Xi, LI Weikang, CHEN Lai, et al. Ethoxy(pentafluoro) cyclotriphosphazene(PFPN) as a multi-functional flame retardant electrolyte additive for lithium-ion batteries[J]. Journal of Power Sources, 2018, 378:707-716. doi: 10.1016/j.jpowsour.2017.12.085
[64]	XIA Lan, XIA Yonggao, LIU Zhaoping. A novel fluorocyclophosphazene as bifunctional additive for safer lithium-ion batteries[J]. Journal of Power Sources, 2015, 278:190-196. doi: 10.1016/j.jpowsour.2014.11.140
[65]	LI Pei, CHEN Yangyang, LI Rui, et al. Stable cycling of high nickel Li-metal batteries with limited Li anode in fluorine rich flame retardant electrolytes[J]. Applied Surface Science, 2022, 593:153434. doi: 10.1016/j.apsusc.2022.153434
[66]	BARELLI L, BIDINI G, OTTAVIANO P A, et al. A novel concept for grid Li-ion BESS safety:Integration of Vanadium-air flow battery technology in fire protection system[J]. Journal of Energy Storage, 2021, 42:103086. doi: 10.1016/j.est.2021.103086
[67]	卓萍, 郭鹏宇, 路世昌, 等. 预制舱式磷酸铁锂电池储能电站防火设计[J]. 消防科学与技术, 2021, 40(3): 426-428.
	ZHUO Ping, GUO Pengyu, LU Shichang, et al. Fire design of prefabricated cabin type lithium iron phosphate battery power station[J]. Fire Science and Technology, 2021, 40(3):426-428.
[68]	曾子琪, 艾新平, 杨汉西, 等. 有机磷酸酯阻燃电解液的研究进展[J]. 电化学, 2020, 26(5):683-693. doi: 10.13208/j.electrochem.200648
	ZENG Ziqi, AI Xinping, YANG Hanxi, et al. Research progress of high-safety phosphorus-based electrolyte[J]. Journal of Electrochemistry, 2020, 26(5):683-693. doi: 10.13208/j.electrochem.200648
[69]	XIANG J, ZHANG Y, ZHANG B, et al. A flame-retardant polymer electrolyte for high performance lithium metal batteries with an expanded operation temperature[J]. Energy & Environmental Science, 2021, 14(6):3510-3521.
[70]	CHEN X, YAN S, TAN T, et al. Supramolecular “flame-retardant” electrolyte enables safe and stable cycling of lithium-ion batteries[J]. Energy Storage Materials, 2022, 45:182-190. doi: 10.1016/j.ensm.2021.11.026

时间	国家	案例
2021.4	中国	北京储能电站发生火灾爆炸事故，造成直接财产损失1 660.81万元
2021.4	美国	亚利桑那州盐河变电站内储能设施发生火灾，自事故发生以来焖烧5天并持续冒烟
2021.4	韩国	韩国一光伏储能系统起火
2021.7	澳大利亚	特斯拉澳大利亚最大储能电站发生火灾
2021.7	法国	一个集装箱内13 t锂电池完全着火，大火持续四天才被扑灭
2022.1	韩国	韩国蔚山南区SK能源公司电池储能大楼发生火灾
2022.1	中国	京港澳高速上一辆载满储能系统的火车突然起火
2022.2	美国	加州Moss Landing储能电站项目发生事故，这是该项目继2021年9月发生电池过热事件后，在不足半年时间里发生的第二起事故
2022.3	中国	中国台湾台中市龙井区龙港路工研院龙井储能场站发生意外失火
2022.3	德国	德国南部某家庭电池储能发生爆炸
2022.4	美国	美国Salt River Project锂离子电池储能系统发生火灾(10 MW)
2022.5	德国	德国卡尔夫区的Althengstett一个用户侧光伏储能系统发生爆炸
2022.6	法国	法国科西嘉岛Poggio-di-Nazzza镇一个光伏发电厂装有锂电的储能集装箱发生火灾，大量浓烟一直在整个东部平原蔓延

灭火剂	灭火原理	灭火效果
CO₂	通过气化达到冷却效果和隔绝氧气的效果来达到灭火效果	可以扑灭明火，降低燃烧温度，减弱爆炸强度，但其冷却效果并不足以一直降低锂电池的温度，阻断电池内部的放热反应，容易发生复燃
七氟丙烷	通过吸收火焰热量达到降温效果，同时分解大量自由基阻断燃烧链式反应	可以有效抑制锂电池火灾，抑制电池复燃，灭火速度快
全氟己酮	快速汽化带走大量热量，同时快速分解成氟化烷自由基，中断燃烧的链式反应	可以有效抑制锂电池火灾，且长效抑制火灾蔓延，防止电池发生复燃
水/细水雾/含添加剂细水雾	隔离氧气、吸热、添加剂化学抑制	可以有效阻止锂电池火灾，降温效果好，有电池短路风险
干粉	隔离氧气和化学抑制	可以扑灭明火，但降温效果不明显
气凝胶	化学抑制和惰性气体的稀释	可以扑灭明火，但降温效果不明显
泡沫	隔离氧气、吸热	可以扑灭明火，有复燃
