智能变电站监控信息自动传动验收方法研究

doi:10.11985/2020.02.015

摘要/Abstract

摘要：

为提升智能变电站监控信息传动验收工作效率,提出基于模拟技术的智能变电站监控信息自动传动验收方法。该方法以变电站系统配置描述文件、远动配置描述文件和监控信息表为基础,应用监控信息自动验收装置模拟主站功能,在调度数据网通道具备前即开展变电站后台监控信息与数据通信网关机转发信息配置同步验收;应用监控信息自动验收装置模拟子站功能,自动触发监控信息,与部署于调度主站的监控信息自动验收模块实时进行程序化自动验收,实现了智能变电站监控信息传动验收的全过程闭环管理,提升了监控信息传动验收工作的准确性与快捷性。

关键词: 智能变电站, 一体化监控系统, 自动验收装置, IEC61850

Abstract:

In order to improve the efficiency of the intelligent substation supervisory and control information transmission acceptance, an automatic transmission acceptance method on the basis of simulation technology is proposed. It is based on the substation system configuration description, the remote configuration description and the substation supervisory as well as control information table. By using the function of simulated dispatching master station, the substation supervisory and control information automatic acceptance device carries out the verification work of the correctness of the substation supervisory and control information and remote information configuration synchronously before the scheduling data network channel is available. By using the function of simulated substation, the automatic acceptance device automatically triggers the supervisory and control information and performs automatic programmatic acceptance of the supervisory and control information with the module deployed in the scheduling main station. The whole process closed-loop management is realized and the accuracy and speed of the intelligent substation supervisory and control information transmission acceptance are improved.

Key words: Smart substation, integrated supervision and control system, automatic acceptance device, IEC61850

中图分类号:

TM734

夏立萌,宋巍,郭飞,王翀,李世群. 智能变电站监控信息自动传动验收方法研究[J]. 电气工程学报, 2020, 15(2): 104-109.

XIA Limeng,SONG Wei,GUO Fei,WANG Chong,LI Shiqun. Research on Automatic Transmission Acceptance Method of Smart Substation Supervisory and Control Information[J]. Journal of Electrical Engineering, 2020, 15(2): 104-109.

图/表 9

图1

图2

图3

图4

图5

图6

图7

图8

图9

参考文献 15

[1]	辛耀中, 石俊杰, 周京阳, 等. 智能电网调度控制系统现状与技术展望[J]. 电力系统自动化, 2015,39(1):2-8.
	Xin Yaozhong, Shi Junjie, Zhou Jingyang, et al. Technology development trends of smart grid dispatching and control systems[J]. Automation of Electric Power Systems, 2015,39(1):2-8.
[2]	汪际峰, 沈国荣. 大电网调度智能化的若干关键技术问题[J]. 电力系统自动化, 2012,36(1):10-16.
	Wang Jifeng, Shen Guorong. Some key technical issues on intelligent power dispatching of bulk power grid[J]. Automation of Electric Power Systems, 2012,36(1):10-16.
[3]	姚建国, 杨胜春, 单茂华. 面向未来互联电网的调度技术支持系统架构思考[J]. 电力系统自动化, 2013,37(21):52-59.
	Yao Jianguo, Yang Shengchun, Shan Maohua. Reflection on operation supporting system architecture for future interconnected power grid[J]. Automation of Electric Power Systems, 2013,37(21):52-59.
[4]	毕艳冰, 蒋林, 王新军, 等. 面向服务的智能电网调度控制系统架构方案[J]. 电力系统自动化, 2015,39(2):92-99.
	Bi Yanbing, Jiang Lin, Wang Xinjun, et al. Service- oriented smart grid dispatching and control system architecture[J]. Automation of Electric Power System, 2015,39(2):92-99.
[5]	杨清波, 李立新, 李宇佳, 等. 智能电网调度控制系统试验验证技术[J]. 电力系统自动化, 2015,39(1):194-199.
	Yang Qingbo, Li Lixin, Li Yujia, et al. Test and verification technology for smart grid dispatching and control systems[J]. Automation of Electric Power Sys- tems, 2015,39(1):194-199.
[6]	彭晖, 陶洪铸, 严亚勤, 等. 智能电网调度控制系统数据库管理技术[J]. 电力系统自动化, 2015,39(1):19-25.
	Peng Hui, Tao Hongzhu, Yan Yaqin, et al. Data base management technology for smart grid dispatching and control systems[J]. Automation of Electric Power Sys- tems, 2015,39(1):19-25.
[7]	高磊, 卜强生, 袁宇波, 等. 基于二次回路比对的智能变电站调试及安全措施[J]. 电力系统自动化, 2015,39(20):130-134.
	GAO Lei, Bu Qiangsheng, Yuan Yubo, et al. Smart substation commissioning and safety measures based on secondary circuit comparison[J]. Automation of Electric Power Systems, 2015,39(20):130-134.
[8]	夏立萌, 张金祥, 宋巍, 等. 基于模拟技术的智能变电站远动信息快速校验方法[J]. 电气应用, 2018,37(13):12-17.
	Xia Limeng, Zhang Jinxiang, Song Wei, et al. Fast verification method for remote information of intelligent substation based on simulation technology[J]. Electro- technical Application, 2018,37(13):12-17.
[9]	李瑞生, 李燕斌, 周逢权. 智能变电站功能架构及设计原则[J]. 电力系统保护与控制, 2010,38(17):24-27.
	Li Ruisheng, Li Yanbin, Zhou Fengquan. The functional frame and design principles of smart substation[J]. Power System Protection and Control, 2010,38(17):24-27.
[10]	笃竣, 祁忠. 基于IEC61850的变电站新型远动网关机[J]. 电力自动化设备, 2011,31(2):113-115.
	Du Jun, Qi Zhong. Telecontrol gateway of substation based on IEC61850[J]. Electric Power Automation Equip- ment, 2011,31(2):113-115.
[11]	张小易, 彭志强. 智能变电站站控层测试技术研究与应用[J]. 电力系统保护与控制, 2016,44(5):88-94.
	Zhang Xiaoyi, Peng Zhiqiang. Research and application on substation level test technology of smart substations[J]. Power System Protection and Control, 2016,44(5):88-94.
[12]	刘焕志, 胡剑锋, 李枫, 等. 变电站自动化仿真测试系统的设计和实现[J]. 电力系统自动化, 2012,36(9):109-115.
	Liu Huanzhi, Hu Jianfeng, Li Feng, et al. Design and implementation of simulation test system for substation automation[J]. Automation of Electric Power Systems, 2012,36(9):109-115.
[13]	纪陵, 李忠明, 蒋衍君, 等. 智能变电站二次系统仿真测试和集成调试新模式的探索和研究[J]. 电力系统保护与控制, 2014,42(22):119-123.
	Ji Ling, Li Zhongming, Jiang Yanjun, et al. Exploration and research of smart substation secondary system simulation testing and integration testing new mode[J]. Power System Protection and Control, 2014,42(22):119-123.
[14]	陆承宇, 阮黎翔, 杜奇伟, 等. 智能变电站远动信息快速校核方法[J]. 电力系统保护与控制, 2015,43(11):128-133.
	Lu Chengyu, Ruan Lixiang, Du Qiwei, et al. A new method for quickly verifying the remote information of smart substation[J]. Power System Protection and Control, 2015,43(11):128-133.
[15]	夏立萌, 郭飞, 顾颖, 等. 基于模拟子站的智能电网调度控制系统集成调试方法[J]. 电气工程学报, 2018,13(6):42-48.
	Xia Limeng, Guo Fei, Gu Ying, et al. Integrated debugging method for smart grid dispatching and control system based on simulated substation[J]. Journal of Elec- trical Engineering, 2018,13(6):42-48.
