强风沙尘环境下车顶复合绝缘子薄弱环节与优化综述*

doi:10.11985/2020.02.001

摘要/Abstract

摘要：

随着高速铁路运行速度的不断提高,对列车车顶高压系统运行性要求也逐渐增加。强风沙尘环境下,车顶复合绝缘子受到了极大的考验,其绝缘性能均出现了不同程度的降低,闪络事故频发,严重影响了高铁的安全稳定运行。首先介绍了强风沙尘环境下车顶绝缘子的薄弱环节并对存在的问题进行了研究,包括撕裂、积污、闪络特性以及磨损等方面。然后对车顶绝缘子的优化方案包括材料配方优化、结构优化及在线检测装置研发等方面进行了分析。最后指出了车顶复合绝缘子亟需解决的问题和未来研究发展的方向,希望从绝缘子材料配方、伞裙和高压绝缘系统结构以及绝缘子状态监测系统入手,提高动车组高压系统运行可靠性。

关键词: 强风沙尘环境, 车顶绝缘子, 闪络, 薄弱环节, 优化

Abstract:

With the continuous improvement of high-speed railway operation speed, the operational requirements of high-pressure system on the train roof are gradually increasing. Under the strong wind and dust environment, the roof composite insulator is greatly tested, and its insulation performance is reduced to varying degrees. Flashover accidents frequently occur, which seriously affects the safe and stable operation of the high-speed rail. The weak links and research problems of the roof insulator under working conditions are introduced, and the optimization scheme of the roof insulator is studied, including material formulation optimization, structure optimization and online detection device development. Finally, the problems that need to be solved in the composite insulator of the roof and the direction of future research and development are pointed out. It is hoped that the operation reliability of electrical multiple unit (EMU) high voltage system can be improved by starting with insulator material formula, high voltage insulation system structure and insulator condition monitoring system.

Key words: Strong wind and dust environment, composite insulator, flashover, weak link, optimization

中图分类号:

TM85

向奕同, 陈攀, 赵玉顺. 强风沙尘环境下车顶复合绝缘子薄弱环节与优化综述^*[J]. 电气工程学报, 2020, 15(2): 1-10.

XIANG Yitong, CHEN Pan, ZHAO Yushun. Overview of Weak Links and Optimization of Roof Composite Insulator in High-speed Sand Environment[J]. Journal of Electrical Engineering, 2020, 15(2): 1-10.
