DC Current Component Suppression and Parameters Design for Grid-connected Inverter

YU Bin¹(), XIE Min¹(), GAO Bo²(), SUN Hui²(), DING Jinjin²(), ZHANG Feng²(), WANG Peng³(), XIAO Huafeng³()

1. State Grid Anhui Electric Power Co., Ltd., Hefei 230001
2. Electric Power Research Institute of State Grid Anhui Electric Power Co., Ltd., Hefei 230601
3. School of Electrical Engineering, Southeast University, Nanjing 210096

Received:2021-01-07 Revised:2021-03-01 Online:2021-09-25 Published:2021-10-29
Contact: XIAO Huafeng E-mail:ee.yubin@foxmail.com;xiem261x@ah.sgcc.com.cn;gb506@126.com;987712670@qq.com;djinjin123@126.com;stuzhangfeng@sina.com;wp471978853@outlook.com;xiaohf@seu.edu.cn

摘要/Abstract

摘要：

非隔离并网逆变器由于具有变换效率高、重量轻、成本低等突出优势,在分布式并网中被广泛应用,但也存在向电网注入直流电流成分的风险。为了消除这个直流成分,有学者提出“虚拟电容”方法,在不增加硬件电路的情况下通过控制算法的方式在逆变器的交流侧等效串联一个电容,起到隔离直流电流的作用。然而,现有虚拟电容法控制器参数的选择没有兼顾进网电流控制器的稳定性和动态性能。为此,提出一种比例谐振控制器和虚拟电容(Proportional resonant controller and virtual capacitor, PR+C)控制器参数优化方法,旨在权衡直流成分抑制速度和进网电流跟踪效果。所提方法中的评价指标简单明了,可为逆变器的控制器参数整定提供指导。

关键词: 非隔离逆变器, 直流成分, 虚拟电容, 参数优化

Abstract:

Transformerless grid-connected inverters have been widely used in distributed grid-connected due to their outstanding advantages such as high conversion efficiency, light weight, and low cost. But this also causes the inverter to inject DC current components into the grid. In order to eliminate this DC component, some scholars have proposed a “virtual capacitor” method, in which a capacitor is connected in series on the AC side of the inverter through a control algorithm without increasing the hardware circuit to isolate the DC current. However, the existing virtual capacitance method controller parameter selection does not consider the stability and dynamic performance of the grid-in current controller. Therefore, a PR+C (Proportional resonant controller and virtual capacitor) controller parameter optimization method is proposed, which aims to balance the DC component suppression speed and the grid-in current tracking effect. The evaluation index in the proposed method is simple and clear, which can provide guidance for the parameter tuning of the inverter controller.

Key words: Transformerless inverters, DC current injection, virtual capacitor, parameters optimization
