微电网储能变流器离网/并网切换控制策略研究

doi:10.11985/2019.02.016

电气工程学报 ›› 2019, Vol. 14 ›› Issue (2): 92-96.doi: 10.11985/2019.02.016

扫码分享

微电网储能变流器离网/并网切换控制策略研究

朱作滨,黄绍平,李振兴,肖意南

湖南工程学院电气信息学院湘潭 411100

收稿日期:2018-09-22 出版日期:2019-06-25 发布日期:2019-10-25
作者简介:朱作滨,男,1988年生,硕士研究生。研究方向为微电网制技术。E-mail：913672953@qq.com。|黄绍平,男,1964年生,硕士,教授。研究方向为微电网控制与保护。

Research on Off Grid / Grid Switching Control Strategy of Micro-grid Power Converter System

ZHU Zuobin,HUANG Shaoping,LI Zhenxing,XIAO Yinan

School of Electronics and Information Engineering, Hunan Institute of Engineering, Xiangtan 411100 China

Received:2018-09-22 Online:2019-06-25 Published:2019-10-25

摘要/Abstract

摘要：

针对微电网储能变流器常规切换模式在离网转并网切换时电压波动、合闸冲击电流大等问题,提出了一种基于相位预同步的控制器状态跟随离网/并网切换控制策略。采用V/f控制器的输出跟随P/Q控制器的输出,同时引入相位预同步模块,使得离网时的相位角与并网相位角同步。最后,建立储能变流器离网/并网切换Matlab/Simulink仿真模型。仿真结果表明,该方法能够有效抑制微网储能变流器离网/并网切换过程中电压波动,并降低合闸冲击电流。

关键词: 储能变流器, 离网/并网, 控制器状态跟随, 相位预同步

Abstract:

In order to solve the problems of voltage fluctuation and large switching impulse current in the off-grid to grid switching mode of micro-grid power converter system, a phase synchronization controller based on state following and off grid/grid switching control strategy is proposed. The output of the V/f controller follows the output of the P/Q controller, and the phase synchronization module is introduced to synchronize the phase angle of the off-grid and the grid-connected phase angle. Finally, the Matlab/Simulink simulation model of the storage grid converter is established. Simulation results show that the proposed method can effectively suppress voltage fluctuation and reduce switching impulse current during off grid/grid switching.

Key words: Power converter system, off grid/grid connection, controller state following, phase presynchronization

中图分类号:

TM64

朱作滨,黄绍平,李振兴,肖意南. 微电网储能变流器离网/并网切换控制策略研究[J]. 电气工程学报, 2019, 14(2): 92-96.

ZHU Zuobin,HUANG Shaoping,LI Zhenxing,XIAO Yinan. Research on Off Grid / Grid Switching Control Strategy of Micro-grid Power Converter System[J]. Journal of Electrical Engineering, 2019, 14(2): 92-96.
