基于模糊神经网络补偿控制器的H型平台同步控制

doi:10.11985/2015.09.009

电气工程学报 ›› 2015, Vol. 10 ›› Issue (9): 54-61.doi: 10.11985/2015.09.009

• 电气工程新技术专刊——本专刊由沈阳工业大学电气工程学院供稿，组稿人为张凤阁教授 • 上一篇下一篇

扫码分享

基于模糊神经网络补偿控制器的H型平台同步控制

张佳媛,王丽梅

沈阳工业大学电气工程学院沈阳 110870

收稿日期:2015-07-23 出版日期:2015-09-25 发布日期:2015-09-25
作者简介:张佳媛女 1990年生,硕士研究生,研究方向为直接驱动技术。|王丽梅女 1969年生,教授,博士生导师,研究方向为交流伺服驱动技术。
基金资助:
辽宁省高等学校创新团队项目(201334068);辽宁省高等学校优秀人才支持计划资助项目(LR2013006)

Synchronous Control of Type H Table Based on Fuzzy Neural Network Compensation Controller

Zhang Jiayuan,Wang Limei

Shenyang University of Technology Shenyang 110870 China

Received:2015-07-23 Online:2015-09-25 Published:2015-09-25

摘要/Abstract

摘要：

直线电机驱动的H型数控平台系统在加工零件时,负载扰动、外部干扰和两电机安装的差异与机械耦合会影响单轴的跟踪精度且会产生同步误差。针对此问题,本文首先用拉格朗日方法给H型平台建模,然后提出一种改进的非奇异终端滑模控制（NTSMC）来进行位置控制器的设计,在不失滑模控制鲁棒性的情况下,有效地削弱了该控制所产生的抖振问题,提高了单轴的跟踪精度。在两轴间采用Sugeno型模糊神经网络（SFNN）补偿控制器来动态补偿H型平台的同步误差。通过模糊神经网络以任意精度逼近非线性系统的能力使同步误差在有限时间内趋近于零,以满足H型平台数控系统的高精度加工要求。仿真结果表明,所设计的控制系统能够有效提高系统的同步控制精度和鲁棒性。

关键词: H型平台, 非奇异终端滑模控制, Sugeno型模糊神经网络补偿控制器, 负载扰动

Abstract:

Load disturbance, external disturbances, difference in the installation of the two motors and the mechanical coupling affect single axis tracking precision and produce synchronous error for linear motors-drive type H table in the processing parts. Aiming at this problem, a lagrangian equation dynamic model for type H table is derived. Then, the improved nonsingular terminal sliding mode control (NTSMC) is adopted for single axis to design position controller. The system not only has strong robustness but also weaken the effects of chattering and improves tracking precision of the single axis. Then, between the two axis using type Sugeno fuzzy neural network (SFNN) compensation controller to dynamic compensate synchronous error of the type H table. Through fuzzy neural network can approximate arbitrary precision of nonlinear system to make the synchronous error tend to be zero in limited time for meeting high precision machining of the H tables. Simulation results show that the designed control system made the type H table possess high synchronous control precision and robustness.

Key words: Type H table, nonsingular terminal sliding mode control, Sugeno type fuzzy neural network compensator, load disturbance

中图分类号:

TM306

张佳媛,王丽梅. 基于模糊神经网络补偿控制器的H型平台同步控制[J]. 电气工程学报, 2015, 10(9): 54-61.

Zhang Jiayuan,Wang Limei. Synchronous Control of Type H Table Based on Fuzzy Neural Network Compensation Controller[J]. Journal of Electrical Engineering, 2015, 10(9): 54-61.

图/表 11

图1

图2

图3

图4

图5

图6

图7

图8

图9

图10

图11

参考文献 12

[1]	刘强, 张从鹏 . 直线电机驱动的H型气浮导轨运动平台[J]. 光学精密工程, 2007,10(15):1540-1546.
	Liu Qiang, Zhang Congpeng . H-type air-bearing motion stage driven by linear motors[J]. Optics and Precision Engineering, 2007,10(15):1540-1546.
[2]	赵冶, 朱煜, 杨开明 , 等. 双边驱动精密XY运动平台解耦控制研究[J]. 组合机床与自动化加工技术, 2010,9:30-33.
	Zhao Zhi, Zhu Yu, Pan Shangfeng . Decoupling control of an H-drive precision XY stage[J]. Combination Machine Tools and Automatic Processing Technology, 2010,9:30-33.
[3]	王丽梅, 金抚颖, 孙宜标 . 基于等效误差法的直线电机XY平台二阶滑模控制[J]. 中国电机工程学报, 2010,30(6):88-92.
	Wang Limei, Jin Fuying, Sun Yibiao . Second order sliding mode control for linear motor XY table based on equivalent errors method[J]. Proceedings of the CSEE, 2010,30(6):88-92.
[4]	王丽梅, 郭宜兴 . 基于混合误差迭代学习控制的XY平台轮廓控制[J]. 制造业自动化, 2013,35(12):14-17.
	Wang Limei, Guo Yixing . XY table contouring control based on hybrid error iterative learning control[J]. Manufacturing Automation, 2013,35(12):14-17.
[5]	张晓光, 赵克, 孙力 . 永磁同步电动机混合非奇异终端滑模变结构控制[J]. 中国电机工程学报, 2011,31(27):116-122.
	Zhang Xiaoguang, Zhao Ke, Sun Li . Hybrid nonsingular terminal sliding mode control for permanent magnet synchronous motor drive system[J]. Proceedings of the CSEE, 2011,31(27):116-122.
[6]	张志峰, 唐任远, 朱建光 , 等. 感应电机磁链和转矩的非奇异终端滑模控制[J]. 电机与控制学报, 2010,14(12):47-51.
	Zhang Zhifeng, Tang Renyuan, Zhu Jianguang , et al. Nonsigular terminal sliding mode control of flux and torque for induction motor[J]. Electric Machines and Control, 2010,14(12):47-51.
[7]	孙宜标, 李萌萌 . 基于PDFF双直线电机二阶滑模交叉耦合控制[J]. 组合机床与自动化加工技术, 2008,6:55-58.
	Sun Yibiao, Li Mengmeng . Second order sliding mode cross coupling control for dual linear motors based on PDFF[J]. Combination Machine Tools and Automatic Processing Technology, 2008,6:55-58.
[8]	Wang Limei, Tang Yaping . Fuzzy cross-coupling control for dual linear motors based on preview feedforward compensation[C]. IEEE International Conference on Mechatronics and Automation, 2009,9(12):2138-2142.
[9]	罗品奎, 金建新, 李小平 . 双直线电机的H型运动平台同步控制研究[J]. 电气与自动化, 2013,62(7):158-161.
	Luo Pinkui, Jin Jianxin, Li Xiaoping . Research on dual linear motor synchronous control in H-type stage[J]. Electrical and Automation, 2013,62(7):158-161.
[10]	徐春梅 . 模糊神经网络补偿的伺服系统二次型最优控制[J]. 控制工程, 2009,16(3):264-267.
	Xu Chunmei . Quadratic optimal control based on fuzzy neural networks compensation for servo system[J]. Control Engineering of China, 2009,16(3):264-267.
[11]	Chen ChinSheng, Lee ChaoFeng, Chou PoHuan , et al. T-S fuzzy tracking and synchronous control in a gantry stage[J]. IEEE International Conference on Fuzzy Systems, 2011: 1844-1851.
[12]	孙海蓉 . 模糊神经网络的研究及其应用[D]. 北京:华北电力大学, 2006.
