一种降低电机附加损耗的槽形优化方法

梁娜,鲍晓华

  1. 合肥工业大学 工业节电与电能质量控制省级协同创新中心 合肥 230009
  • 收稿日期:2016-04-08 出版日期:2017-09-25 发布日期:2020-03-27
  • 作者简介:梁 娜 女,1993年生,硕士研究生,主要方向为电机电磁场有限元分析。|鲍晓华 男,1972年生,教授,博士生导师,主要研究方向为电机优化设计及电磁场分析。
  • 基金资助:
    安徽省工业节电与电能质量控制协同创新中心开放题基金资助项目(KFKT201505)

A Slot Optimization Method for Reducing Motor’s Additional Loss

Na Liang,Xiaohua Bao

  1. School of Electrical Engineering and Automation, Hefei University of Technology Hefei 230009 China
  • Received:2016-04-08 Online:2017-09-25 Published:2020-03-27

摘要:

改变槽形结构作为一种简单易实施的方法被广泛地应用在电机的各项性能优化中。本文探讨了一种以降低电机附加损耗为目的的转子槽形的优化设计,首先分析了转子槽各个尺寸与附加损耗间的变化关系,并对其进行函数拟合得到对应于附加损耗最小值的一组尺寸,再根据电机设计的其他要求对尺寸变量进行迭代调整得到最佳的槽形参数。该研究可以为电机的优化设计提供参考思路。

关键词: 附加损耗, 槽形优化, 有限元分析

Abstract:

As a simple and easy completing method, the changing slot structure is widely used in optimization of motor’s performances. The optimization of rotor slot aimed at reducing motor’s additional loss was studied in this paper. The relationship between dimensions of rotor slot and additional loss were analyzed in the first step. Then the set of dimensions for the minimum additional loss was obtained by function fitting. The other requirements of motor’s designs were also considered in the iterative calculation for the optimum geometry. This study could provide a reference for motor’s optimization in engineering practice.

Key words: Additional loss, slot optimization, finite element analysis
