考虑接地导体时500kV开关场内的工频电场

电气工程学报 ›› 2015, Vol. 10 ›› Issue (10): 9-14.

考虑接地导体时500kV开关场内的工频电场

李永明¹,王洋洋¹,罗鹏¹,徐禄文²

^1. 重庆大学输配电装备及系统安全与新技术国家重点实验室重庆 400044
^2. 重庆电力科学试验研究院重庆 401123

收稿日期:2015-06-18 出版日期:2015-10-25 发布日期:2020-01-03
作者简介:Yongming Li（李永明）, male, born in 1964, Doctor, Associate professor. Major research interests include the theory and calculation method of electromagnetic field, the electromagnetic compatibility of power system and automotive.|Yangyang Wang（王洋洋）, female, born in 1990, Master, Major research interests include the numerical calculation of electromagnetic field and the electromagnetic environment around the transmission line.

The Power Frequency Electric Field in 500kV Swtiching Yard with Considering the Earth Electrode

Li Yongming¹,Wang Yangyang¹,Luo Peng¹,Xu Luwen²

^1. State Key Laboratory of Power Transmission Equipment & System Security and New Technology Chongqing University Chongqing 400044 China
^2. Chongqing Electric Power Test & Research Institute Chongqing 401123 China

Received:2015-06-18 Online:2015-10-25 Published:2020-01-03
Supported by:
Project supported by National Natural Science Foundation of China(51277189);Program of Introducing Talents of Discipline to Universities(B08036);Fundamental Research Funds for the Central Universities(CDJXS12151108)

摘要/Abstract

摘要：

为了深入研究变电站内工频电场在有无考虑站内电气设备接地体影响时的分布情况,本文推导了计算开关场内工频电场的三维模拟电荷法,以500kV变电站为例,对变电站500kV开关场及各类电气设备的接地体进行建模,并进行工频电场分布的计算分析。首先,通过仿真结果与实测结果的对比,验证所建模型的正确性;然后分析了变电站站内有无电气设备接地体影响时的工频电场分布情况。本文所提方法为考虑接地体影响时站内工频电场的计算与分析提供了一种有效、快捷的途径。

关键词: 变电站, 开关场, 模拟电荷法, 工频电场, 接地体, 安全防护等级

Abstract:

The distribution of power frequency electric field in the substation under the influence of the earth electrode is studied in this paper. Firstly, the charge simulation method for the calculation of power frequency electric field in switch yard is derived in this paper, and the electric field of 500kV switch yard is analyzed in a 500kV substation with the earth electrode. Secondly, the modeling of the substation is established. Finally, numerical results are compared to that of measurement for verifying the correctness of the model; then the power frequency electric field distribution in switch yard is analyzed whether the earth electrode of electrical equipment. This work provides an effective, efficient way for the calculation and analysis of the power frequency electric field in the substation with the existence of earth electrode.

Key words: Substation, switching yard, charge simulation method, electric field, earth electrode, the level of security

中图分类号:

TM631

李永明,王洋洋,罗鹏,徐禄文. 考虑接地导体时500kV开关场内的工频电场[J]. 电气工程学报, 2015, 10(10): 9-14.

Li Yongming,Wang Yangyang,Luo Peng,Xu Luwen. The Power Frequency Electric Field in 500kV Swtiching Yard with Considering the Earth Electrode[J]. Journal of Electrical Engineering, 2015, 10(10): 9-14.

图/表 10

参考文献 15

[1]	Liu Zhenya. UHV power network[M]. Beijing: China Economy Press, 2006.
[2]	Liang Zhenguang, Dong Xia, Zheng Lu . Measurement and analysis of power frequency electric field in a 500 kV substation[J]. High Voltage Engineering, 2006,32(11):81-83.
[3]	Sun Tao, Wan Baoquan . The measurement of electromagnetic environment parameters in 500kV substation[J]. High Voltage Engineering, 2006,32(6):51-55.
[4]	Yu Jihui, Zhang Huaiqing, Li Yongming . The radial basis data function method for electromagnetic measurement[J]. High Voltage Engineering, 2008,34(11):2417-2422.
[5]	Xu Luwen, Li Yongming, Liu Changsheng , et al. Analysis on power frequency electric and magnetic fields within 500 kV substations in chongqing area[J]. Power System Technology, 2008,32(2):66-70.
[6]	Wan Baoquan, Xie Huichun, Fan Liang , et al. Electromagnetic environment and corona control measures of UHV substations[J]. High Voltage Engineering, 2010,36(1):109-115.
[7]	Wang Wenbing, Cong Jun, Zhang Bin . A new 220kV substation surrounding electromagnetic environment monitoring and analysis[J]. China Resources Comprehensive Utilization, 2008,126(5):21-23.
[8]	Bai Feng, Qi Lei, Cui Xiang , et al. Prediction of stead-state electromagnetic disturbance in UHV substation[J]. High Voltage Engineering, 2009,35(8):1836-1841.
[9]	Ye Qing, Wen Yuanfang, Mo Ran , et al. Calculation of power frequency electromagnetic field within substation by moment method and actual measured results[J]. Power System Technology, 2012,36(2):189-194.
[10]	Du Zhiye, Ruan Jiangjun, Gan Zheyuan , et al. Three-dimensional numerical simulation of power frequency electromagnetic field inside and outside substation[J]. Power System Technology, 2012,36(4):229-235.
[11]	Li Naiyi, Yang Xi, Peng Zongren . Measurement of electric fields around a 1000kV UHV substation[J]. IEEE Transactions on Power Delivery, 2013,28(4):2356-2362. doi: 10.1109/TPWRD.2013.2269146
[12]	Xiong Changshou, Chen Tao, Yang Fan , et al. Calculation method of power frequency electric field in high voltage substation considering the interference from switching equipment[J]. High Voltage Apparatus, 2012,48(11):50-57.
[13]	Wang Zezhong, Liu Shili, Sun Jing . Calculation of power frequency electric field near equipment in UHV AC substations[J]. High Voltage Engineering, 2010,36(1):81-85.
[14]	Lee B Y, Park J K, Min S W , et al. An effective modeling method to analyze electric field around transmission lines and substation using a generalized finite line charge[J]. IEEE Transactions on Power Delivery, 1997,12(3):1143-1150. doi: 10.1109/61.636926
[15]	Adel Z E D, Mohamed A A W . The effects of the span configurations and conductor sag on the electric-field distribution under overhead transmission lines[J]. IEEE Transactions on Power Delivery, 2010,25(4):2891-2902. doi: 10.1109/TPWRD.2010.2051340
