Technical Scheme of Substation Safety Operation and Maintenance Device

doi:10.11985/2020.04.014

Abstract

Abstract:

Now in the substation whether it is production equipment operation or production system operation, the intervention of external PC or USB are needed, which brings great insecurity and management difficulty, a safety operation and maintenance solution is proposed, the program obtains the use of a mobile PC equipment to meet all the operation and maintenance work in the substation. To deal with the complex operation and maintenance environment, the scheme adopts virtualization technology and proposes a set of management methods, which can manage the changes of multiple virtual machines and various states, effectively divide the various operations environment, and simplify the operation process in the operation and maintenance, reduce the focus of the operation and maintenance personnel on the underlying technology, the management of virtual machines is relatively transparent to users, making the internal operation of the substation more safer, easy to use, controllable and efficient, and a pilot project proves that the operation and operation device is feasible and easy to use.

Key words: Power systems, operations safety, virtualization, cloud computing

CLC Number:

TM561

LI Jin, ZHANG Ximing, XIE Xinglang, LI Heng. Technical Scheme of Substation Safety Operation and Maintenance Device[J]. Journal of Electrical Engineering, 2020, 15(4): 114-120.

Figures/Tables 9

References 21
